Camera |
|
|
Image Sensor |
1/2.8” Progressive Scan CMOS |
|
Effective Pixels |
1920(H)×1080(V) |
|
Electronic Shutter |
Auto/Manual, 1/15 ~ 1/20,000s |
|
Min. illumination |
Color: 0.01 Lux @ (F1.2,AGC ON), B/W: 0 Lux @ (IR LED ON) |
|
S/N Ratio |
55 dB |
|
Day/Night |
Auto(ICR)/Day / Night/Timing |
|
Wide Dynamic Range |
120dB |
|
IR Range |
Up to 45 m (147.6 ft) |
|
IR On/Off Control |
Auto/Manual |
|
Pan/Tilt/Rotation Range |
Pan: 0˚~360˚, Tilt: 0˚~90˚, Rotation: 0˚~360˚ |
|
Lens |
|
|
Lens Type |
Motorized Focus |
|
Iris |
Fixed Iris |
|
Focal Length |
2.7 ~ 13.5mm |
|
F Number |
F1.6 |
|
Angle of View |
H: 105°~ 30°, V: 55°~15° |
|
Video |
|
|
Max. Resolution |
2MP (1920×1080) |
|
Streaming Capability |
3 Streams |
|
Stream/Frame Rate |
Stream1: 1920×1080, 1280×720 @ 25/30fps Stream2: D1, VGA, 640×360, CIF, QVGA @ 25/30fps Stream3: VGA, CIF, QVGA @ 25/30fps |
|
Bit Rate Control |
CBR/VBR |
|
Bit Rate |
Stream1: 100kbps ~ 12Mbps Stream2: 10kbps ~ 6Mbps Stream3: 10kbps ~ 3Mbps |
|
Image Enhancement |
HLC/BLC/Anti-shake/Defog /WDR |
|
White Balance |
Auto/Tungsten/Fluorescent/Daylight/Shadow/Manual |
|
Gain Control |
Auto/Manual |
|
Noise Reduction |
2D/3D DNR |
|
Smart IR |
Support |
|
Mirror |
Support |
|
Aisle Mode |
N/A |
|
Region of Interest |
Off/On (8 Zone, Rectangle) |
|
Motion Detection |
Support |
|
Privacy Masking |
Support |
|
Audio |
|
|
Built-in Mic |
Yes |
|
Built-in Speaker |
Yes |
|
Audio Compression |
G.711, RAW_PCM |
|
Bit Rate |
8kbps, 16kbps, 64kbps |
|
Network |
|
|
Protocols |
IPv4/IPv6, 802.1x, HTTP, HTTPS, TCP/IP, UDP/IP, RTSP, DHCP, NTP, RTCP/RTP, PPPoE, SMTP, DNS, UPnP, FTP, ARP, SNMP, TLS/SSL |
|
Interoperability |
ONVIF, SDK, CGI |
|
Streaming Method |
Unicast |
|
Max. User Access |
10 Users |
|
Web Viewer |
<IE11, Chrome, Firefox , Microsoft Edge |
|
Management Software |
SunView |
|
Intelligence |
|
|
Intelligent Detection |
Intrusion (support accurate detection of vehicle and human) |
|
Smart Alarm |
Supports sound and light alarm linkage. When an alarm is triggered, the camera links sound alarm and light flashing |
|
Interface |
|
|
Ethernet |
1 Ethernet (10/100 Base-T) RJ-45 Connector |
|
Audio |
1ch Input, 1ch Output |
|
Alarm |
1ch Input, 1ch Output |
|
Reset Button |
Support |
|
Storage |
Built-in Micro SD card slot, up to 256GB |
|
Electrical |
|
|
Power Supply |
DC12V/POE (IEEE 802.3af) |
|
Power Consumption |
Max 8.5 W |
|
Operating Temperature |
-40°C ~ 50°C (-40°F ~ 122°F ) |
|
Operating Humidity |
Less than 90% RH |
|
Ingress Protection |
IP66 |
|
Certifications |
CE/FCC |
|
Casing |
Metal |
|
Dimensions |
303 × 100 × 107 mm (11.9 × 3.94 × 4.21 inch) |
|
Net Weight |
1.24 kg (2.73 lb) |
