Temperature Measurement |
|
|
Temperature Range |
28 °C to 42 °C (82.4°F to 107.6°F) |
|
Sensor |
Uncooled Microbolometer |
|
Resolution |
120×90 |
|
Measurement Deviation |
±0.3 °C, Environment temperature: 20 °C ~ 35 °C (68°F ~ 95°F), No airflows indoor |
|
Measurement Accuracy |
0.1 |
|
Measuring Distance |
0.5 to 1.2 m (1.64 to 3.94 ft) |
|
Response Speed |
≤ 100ms |
|
Basic |
|
|
Display |
7-inch LCD touch screen |
|
Camera |
Dual-lens |
|
Sensor |
1/2.8” 2MP Progressive Scan CMOS |
|
WDR |
120dB |
|
Light Compensation |
Auto white light, Auto IR light |
|
Storage Capacity |
RAM: 1GB, EMMC: 8GB |
|
Function |
|
|
Authentication Mode |
Face, Body temperature, Mask Detection optional |
|
Face Recognition Distance |
0.3 to 2.0 m (0.98 to 6.56 ft) |
|
Face Anti-Spoofing |
Support |
|
Audio Prompt |
Support |
|
Face Recognition Accuracy |
≥ 99.8% |
|
Face Recognition Time |
≤ 0.2 s |
|
Face Image Capacity |
30,000 |
|
Record Capacity |
60,000 event capacity |
|
Interface |
|
|
Ethernet |
1 RJ45 10M/100M Ethernet port |
|
Alarm |
3-ch alarm input, 1-ch alarm output |
|
Wiegand Input |
1 (Support peripheral card reader ) |
|
Wiegand Output |
1 (WG26, WG34) |
|
USB |
1 USB 2.0 port |
|
Door Lock Output |
1 (Switch quantity) |
|
General |
|
|
Power Supply |
12V 2A DC |
|
Power Consumption |
Max 8 W |
|
Working Temperature |
0 °C to 50 °C (32 °F to 122 °F) For temperature measurement: 20 °C ~ 35 °C (68°F ~ 95°F) |
|
Working Humidity |
0～90%, no condensing |
|
Dimensions (L× W×H) |
120 × 28 × 256 mm (4.72 × 1.10 × 10.08 inch) |
|
Net Weight |
1 kg (2.2 lb) |
